UCFL208-24 Pillow Block Flange Mounted Bearing – 1-1/2" Bore

Introduction

The UCFL208-24 Pillow Block Flange Mounted Bearing is engineered for industrial applications requiring high load capacity, dependable shaft support, and efficient use of mounting space. Featuring a 1-1/2-inch bore and a two-bolt oval flange housing, this mounted bearing unit provides a compact yet rugged solution for larger shafts without requiring the footprint of a four-bolt flange.

Its durable cast iron housing delivers excellent structural strength, while the self-aligning insert bearing accommodates minor shaft misalignment to reduce vibration and promote smoother operation. This design helps extend bearing life while maintaining reliable performance in demanding industrial environments.

With a 5,125 lb dynamic load rating, 4,091 lb static load rating, and a maximum operating speed of 3,300 RPM, the UCFL208-24 is an excellent choice for conveyor systems, agricultural machinery, material handling equipment, processing machinery, and industrial power transmission applications.

Hero Product Snippet

Designed for demanding industrial applications, the UCFL208-24 combines a compact two-bolt oval flange with dependable shaft support for 1-1/2-inch shafts.

Recommended Applications

• Conveyor systems
• Agricultural machinery
• Material handling equipment
• Industrial processing equipment
• Recycling machinery
• Woodworking equipment
• Production lines
• Power transmission systems

Compact Two-Bolt Oval Flange Design

The UCFL Series features a space-saving two-bolt oval housing that simplifies installation while maintaining excellent mounting stability for industrial equipment.

Heavy-Duty Cast Iron Housing

Its cast iron housing provides excellent rigidity and resistance to vibration, making it well suited for continuous-duty industrial applications.

Self-Aligning Bearing Insert

The self-aligning insert bearing accommodates minor shaft misalignment, helping reduce wear while maintaining smooth and reliable operation.

Reliable Load Capacity

With a 5,125 lb dynamic load rating and 4,091 lb static load rating, the UCFL208-24 provides dependable support for medium and heavy-duty industrial machinery.

Easy Relubrication and Maintenance

A built-in grease fitting allows routine lubrication, helping maximize bearing life while minimizing maintenance downtime.

Key Features

• UCFL208-24 model
• Two-bolt oval flange housing
• 1-1/2" bore
• Cast iron housing
• Self-aligning insert bearing
• 5,125 lb dynamic load rating
• 4,091 lb static load rating
• Maximum speed: 3,300 RPM
• Relubricatable design
• Ideal for medium and heavy-duty industrial equipment

FAQ

What is the difference between the UCFL208-24 and the UCF208-24?

The UCFL208-24 features a two-bolt oval flange, while the UCF208-24 uses a four-bolt square flange. The UCFL design is ideal where mounting space is limited.

Where is this bearing commonly used?

It is commonly installed in conveyor systems, agricultural machinery, material handling equipment, industrial processing machinery, and production lines.

What material is the housing made from?

The housing is manufactured from durable cast iron.

What is its load capacity?

The unit features a 5,125 lb dynamic load rating and a 4,091 lb static load rating.

Can it compensate for shaft misalignment?

Yes. The self-aligning insert bearing accommodates minor shaft misalignment for smoother operation and longer bearing life.

Is the UCFL208-24 relubricatable?

Yes. The housing includes a grease fitting for routine lubrication and easier maintenance.
