ANSI No |
#CA550 | LENGTH | 10 ft |
| PITCH | 1.61 inch (41.1 mm) | ROLLER DIAMETER (D1 MAX) |
0.66 inch (16.87 mm) |
| WIDTH BETWEEN PLATES (B1 MIN) |
0.77 inch (19.81 mm) | PIN DIAMETER (D2 MAX) |
0.28 inch (7.19 mm) |
| PIN LENGTH (L MAX) |
1.37 inch (35 mm) | PIN LENGTH (LC MAX) |
1.49 inch (38 mm) |
| INNER PLATE DEPTH (H2 MAX) |
0.75 inch (19.3 mm) | PLATE THICKNESS (T MAX) |
0.11 inch (2.8 mm) |
| ULTIMATE TENSILE STRENGTH (QMIN) |
39.10/8886 kN/LB | WEIGHT | 1.94 lb/ft (0.87 kg/m) |
