#50 Roller Chain x 50 feet
ANSI Chain No.: #50
Length: 50 feet
Pitch (P): 0.625 inch (15.875 mm)
Roller Diameter (d1 max): 0.4 inch (10.16 mm)
Width Between Inner Plates (b1 min): 0.370 inch (9.4 mm)
Pin Diameter (d2 max): 0.2 inch (5.08 mm)
Pin Lenght (L max): 0.815 inch (20.70 mm)
Pin Lenght (Lc max): 0.874 inch (22.20 mm)
Inner Plate Depth (h2 max): 0.594 inch (15.09 mm)
Plate Thickness (T max): 0.080 inch (2.03 mm)
Ultimate Tensile Strenght (Q min): 22.20/5045 kN/LB
Average Tensile Strenght (Qo): 29.4 kN
Weight (q): 0.685 lb/ft (1.02 kg/m)
ANSI Chain No.: #50
Length: 50 feet
Pitch (P): 0.625 inch (15.875 mm)
Roller Diameter (d1 max): 0.4 inch (10.16 mm)
Width Between Inner Plates (b1 min): 0.370 inch (9.4 mm)
Pin Diameter (d2 max): 0.2 inch (5.08 mm)
Pin Lenght (L max): 0.815 inch (20.70 mm)
Pin Lenght (Lc max): 0.874 inch (22.20 mm)
Inner Plate Depth (h2 max): 0.594 inch (15.09 mm)
Plate Thickness (T max): 0.080 inch (2.03 mm)
Ultimate Tensile Strenght (Q min): 22.20/5045 kN/LB
Average Tensile Strenght (Qo): 29.4 kN
Weight (q): 0.685 lb/ft (1.02 kg/m)
